This guide explains how to prepare a robotic 3D print using the Vertical Slicer component in Grasshopper.

‍

1. Add Your Geometry

Begin by modeling the object you want to print.

Example used in the video: a simple bench
‍

Steps

• Create your geometry in Rhino
• Connect it to the Vertical Slicer component
• When correctly connected:
  🔸 Orange components → turn gray

That confirms the slicer is receiving valid geometry.
‍

2. Configure Slicing Parameters

These settings define how the robot prints the object.
‍

Basic print settings:

• Robot speed
• Module name
  (This becomes both the file name and the RAPID procedure name)
• Initial layer height / total layer height
• Number of surface approximation points (for curved surfaces)
• Start scene position
• Zone data (corner smoothing)
  ‍

3. Work Object & Print Bed Setup

This defines the robot’s reference frame and where the print sits.
‍

Work Object

Represents the robot’s coordinate reference.
‍

Set:

• Work object name
• Position (typically the left outer corner of the robot workspace)
• X, Y, Z values
  (Usually constant once calibrated)
  ‍

Print Bed

Defines the printable area.
‍

Set:

• Print bed width
• Print bed length
• Exact print location on the bed
  ‍

The slicer also supports rotating planes if your setup requires them.
‍

4. Track Settings (If Using a Linear Track)

Choose how the robot moves along the track.
‍

Available modes
‍

Manual position

• Uses a fixed millimeter value
• Updates live
  ‍

Automatic position

• Finds an optimal track position
  ‍

Moving track

• Track moves during printing

📌 Recommendation:

• Use Manual or Automatic for most prints
• Only use moving track when the object is larger than the print bed
  (track motion reduces accuracy)
  ‍

5. Run the Simulation

Before exporting code, validate the motion.
‍

Setup

• Confirm correct robot model
• Select track (if used)
• Choose print head
  Example: 2K print head
• Set simulation start point → 0 recommended
  ‍

Run

• Press Playback
• Use the playback popup controls

⚠️ The simulation is very accurate, but complex prints should still be verified later in RobotStudio with the real controller.
‍

6. Export the Robot Code (RAPID)

After a successful simulation, generate the printing program.
‍

Method 1 — Direct Export

• Choose folder
• Write the file
  ‍

Method 2 — Manual (shown in video)

• Copy code from the panel
• Paste into Visual Studio Code
• Save as: .mod
‍

If the ABB RAPID extension is installed → syntax highlighting helps verify errors.
‍

7. Send to the Robot

• Save the .mod file to a USB
• Upload it to the robot controller
• Start the print
  ‍

✔ The robot is now ready to print using the Vertical Slicer workflow.
